| Sensorius |
1/1.8" Progressive Scan CMOS |
| Min.apšvietimas |
Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Užrakto greitis |
1/3 s to 1/100,000 s |
| Lėtas užraktas |
Yes |
| Diena / naktis |
IR Cut Filter |
| Kampo valdymas |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| WDR |
120 dB |
| Objektyvas |
Fixed lens, 2.8/4/6 mm |
| Diafragma |
F1.6 |
| FOV |
2.8 mm, horizontal FOV: 110.7° , vertical FOV: 59.1° , diagonal FOV: 131° 4 mm, horizontal FOV: 87.1° , vertical FOV: 47.4° , diagonal FOV: 101.8° 6 mm, horizontal FOV: 50.8° , vertical FOV: 27.6° , diagonal FOV: 60° |
| Montavimas |
M16 |
| IR atstumas |
Up to 30 m |
| Bangos ilgis |
850 nm |
| Max.raiška |
3840 × 2160 |
| Pagrindinis srautas |
50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720) |
| Antrinis srautas |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas |
50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas |
Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.264 tipas |
Baseline Profile/Main Profile/High Profile |
| H.265 tipas |
Main Profile |
| Vaizdo bitų greitis |
32 Kbps to 16 Mbps |
| Vaizdo kodavimas |
H.264 and H.265 encoding support |
| Garso suspaudimas |
G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Garso bitų greitis |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Aplinkos triukšmo filtraimas |
Yes |
| Garso dažnis |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Pagrindiniai įvykiai |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Papildoma apsauga |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| ROI |
1 fixed region for main stream, sub-stream and third stream |
| Susiejimas |
Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture |
| Vaizdo gerinimas |
BLC, HLC, 3D DNR |
| Vaizdo nustatymas |
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Day/Night perjungimas |
Day/Night/Auto/Schedule |
| TInklo saugykla |
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protokolai |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Apsauga |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, |
